Spectrum of Platinum homepage

Lines and intensities in the range 1888-1904 Å.


 WAVELENGTH   WAVENUMBER   INTENSITY    CLASSIFICATION     CODE
 ______________________________________________________________

  1888.1064    52963.12      6400     Ne II                  C
  1888.2852    52958.102     5700     Pt II    48591-101549  K
  1888.9330    52939.940     8500     Pt II   109527- 56587  K
  1889.0888    52935.574     1500     Pt I     10131- 63067  N
  1889.28      52930.2         59
  1889.5226    52923.421    58000     Pt II    18097- 71021  K
  1889.6418    52920.083     6000     Pt II   109507- 56587  K
  1889.7120    52918.12      6100     Ne II                  C
  1890.0718    52908.043     2100     Pt II    32918- 85826  K
  1890.50      52896.1        510
  1890.74      52889.3        380     Pt I       775- 53665  N
  1891.04      52881.0        190
  1891.3667    52871.82       420     Ne II                  C
  1891.5305    52867.242     4400     Pt II    29030- 81897  P
  1891.73      52861.7        140
  1892.83      52830.9        420     Pt II    21168- 73999  K
  1893.08      52824.0        650
  1893.31      52817.6        210
  1893.8750    52801.79       900     Ne II                  C
  1894.31      52789.7         65     Pt II   114455- 61665  K
  1894.5483    52783.030     2000
  1895.0088    52770.204    12000     Pt II     8419- 61190  08
  1895.4329    52758.396     7100     Pt II   109346- 56587  K
  1895.84      52747.1        140
  1896.06      52740.9         42
  1896.2921    52734.493     4300     Pt II    23875- 76610  07
  1896.45      52730.1         91
  1897.2321    52708.365     9000     Pt I         0- 52708  D
  1897.37      52704.5        480
  1897.4417    52702.542      700     Pt I     13496- 66198  N
  1897.5769    52698.787    11000     Pt II    13329- 66028  04
  1897.8051    52692.45       360     Ne II                  C
  1898.1722    52682.259    14000     Pt II   104090- 51408  K
  1898.7831    52665.310     2300
  1899.0445    52658.060    12000     Pt II   109676- 57018  K
  1899.6717    52640.675      460     Pt I      6140- 58780  N
  1899.84      52636.0        360     Pt II    29261- 81897  K
  1900.1898    52626.32       650     Ne II                  C
  1900.51      52617.5         47
  1900.72      52611.6        110
  1901.0882    52601.452     1700     Pt II    42031- 94633  K
  1901.4729    52590.810     1300     Pt II   114256- 61665  K
  1901.6478    52585.973     1900     Pt II    23875- 76461  11
  1902.01      52576.0         53     Pt II    58062-110638  K
  1902.26      52569.0         50
  1902.59      52559.9        260     Pt I      6567- 59127  N
  1902.79      52554.4        370
  1903.2186    52542.572    25000     Pt I     10116- 62659  N
  1903.47      52535.6        210
  1903.7676    52527.420     5000     Pt I     10131- 62659  N
  1903.8836    52524.219     6100     Pt II    21717- 74241  07
Character descriptor definitions (appear to right of intensity)
Code definitions

Photoelectric spectrum

1888-1904 Å

                      WAVELENGTH (ANGSTROMS) - VACUUM

A PostScript file is available.
