Spectrum of Platinum homepage

Lines and intensities in the range 1936-1952 Å.


 WAVELENGTH   WAVENUMBER   INTENSITY    CLASSIFICATION     CODE
 ______________________________________________________________

  1936.3772    51642.831      670     Pt II   116689- 65046  K
  1937.00      51626.2        170     Pt II    36484- 88110  K
  1937.24      51619.8        410     Pt I     15501- 67121  N
  1937.4245    51614.915   150000     Pt I       823- 52438  N
  1938.8269    51577.58     60000     Ne II                  C
  1939.8110    51551.414    53000 L   Pt II     9356- 60907  05
  1940.0319    51545.544    32000     Pt I         0- 51545  D
  1940.4766    51533.732     2100     Pt I      6567- 58101  N
  1940.6664    51528.691     1600     Pt I     10116- 61645  N
  1940.93      51521.7        220     Pt II    50564-102086  K
  1941.2409    51513.442     8900 L   Pt I     10131- 61645  N
  1941.60      51503.9        380
  1942.1105    51490.376     5500     Pt II    23875- 75365  K
  1942.8811    51469.954      460     Pt II   121651- 70181  K
  1943.06      51465.2        180
  1943.81      51445.4        120
  1944.3026    51432.323     1000
  1944.4617    51428.116    63000     Pt II    13329- 64757  05
  1944.7712    51419.931     1300     Pt I      6567- 57987  D
  1944.8719    51417.27       560     Ne II                  C
  1945.2210    51408.041     1600     Pt I     13496- 64904  N
  1945.4550    51401.857     2400     Ne II                  A
  1945.4550    51401.857     2400     Ne III                 AL
  1946.0018    51387.414      840     Ne III                 L
  1946.72      51368.5         76
  1947.33      51352.4        540     Pt II    50564-101916  K
  1948.32      51326.3         88
  1948.4820    51322.004      890     Pt II   115060- 63738  K
  1948.64      51317.8        240
  1948.9713    51309.120     5600     Pt II    21717- 73026  07
  1949.6947    51290.08      1000     Ne II                  C
  1949.8139    51286.946     9700     Pt I         0- 51286  D
  1949.9102    51284.413    16000     Pt II    23461- 74745  06
  1950.2777    51274.75       300     Ne II                  C
  1950.51      51268.6        270     Pt II    53749-105018  K
  1951.37      51246.0        120     Pt II    58062-109307  K
  1951.4743    51243.309      450     Pt II   112433- 61190  K
  1951.7297    51236.60       400 U   Ne II                  C
  1951.7701    51235.543     2400     Pt I     10116- 61352  N
Character descriptor definitions (appear to right of intensity)
Code definitions

Photoelectric spectrum

1936-1952 Å

                      WAVELENGTH (ANGSTROMS) - VACUUM
