Spectrum of Platinum homepage

Lines and intensities in the range 1968-1984 Å.


 WAVELENGTH   WAVENUMBER   INTENSITY    CLASSIFICATION     CODE
 ______________________________________________________________

  1968.57      50798.3         43     Pt II    53749-104548  K
  1968.88      50790.3         74
  1969.07      50785.4        100
  1969.2802    50779.976     4000     Pt II    23461- 74241  07
  1969.6807    50769.651    20000     Pt I       775- 51545  D
  1970.0007    50761.403     9200     Pt II   104636- 53875  P
  1970.33      50752.9        340     Pt I     13496- 64248  N
  1970.6936    50743.554      320     Pt II    23875- 74619  08
  1971.00      50735.7        110     Pt II    32237- 82972  K
  1971.5374    50721.838    51000     Pt I       823- 51545  N
  1971.73      50716.9        250     Pt II    42031- 92749  K
  1973.4663    50672.261      370     Pt II   115060- 64388  K
  1974.54      50644.7        210     Pt II    54373-105018  K
  1974.78      50638.6         41     Ne III                 L
  1975.32      50624.7        150
  1975.45      50621.4        150
  1976.7900    50587.063      540     Pt II    32237- 82824  K
  1977.12      50578.6        400
  1977.6654    50564.67       330     Ne II                  C
  1978.31      50548.2         82
  1978.6960    50538.334     2400     Pt II    23461- 73999  P
  1978.8444    50534.544    19000     Pt II   104410- 53875  K
  1979.39      50520.6        130
  1979.5138    50517.455     1700     Pt II   114256- 63738  K
  1979.7647    50511.054    37000     Pt I       775- 51286  D
  1979.8876    50507.918     3100     Pt II    27255- 77763  K
  1980.63      50489.0        330
  1980.90      50482.1        120
  1981.09      50477.3         53
  1981.2072    50474.277      390     Pt I      6567- 57041  N
  1982.34      50445.4         95
  1982.5759    50439.43       310     Ne II                  C
  1983.7486    50409.614    18000     Pt II    13329- 63738  05
Character descriptor definitions (appear to right of intensity)
Code definitions

Photoelectric spectrum

1968-1984 Å

                      WAVELENGTH (ANGSTROMS) - VACUUM

A PostScript file is available.
