Lines and intensities in the range 1984-2000 Å.


 WAVELENGTH   WAVENUMBER   INTENSITY    CLASSIFICATION     CODE
 ______________________________________________________________

  1984.23      50397.4         96     Pt II    46046- 96443  K
  1984.31      50395.4         71
  1984.5698    50388.754     3700     Pt II   114127- 63738  K
  1985.4693    50365.926      160     Pt II    23875- 74241  09
  1986.59      50337.5        130     Pt II   113119- 62781  K
  1986.8846    50330.049      970     Pt I     13496- 63826  N
  1987.2168    50321.637      170     Pt I       775- 51097  D
  1987.6987    50309.436     1500     Pt I     10131- 60441  N
  1987.7868    50307.206    13000     Pt I     10116- 60423  N
  1987.8582    50305.400     2200     Pt II    24879- 75184  05
  1988.0622    50300.236     5900     Pt II    23461- 73761  10
  1988.71      50283.9        230
  1989.0626    50274.939     1000 U   Ne II                  A
  1989.0626    50274.939          U   Si I                   A
  1989.1056    50273.852    23000     Pt I       823- 51097  D
  1989.2257    50270.816      200
  1989.65      50260.1         75     Pt II    58062-108322  K
  1990.5751    50236.738    32000     Pt II    15791- 66028  05
  1990.75      50232.3        260     Pt II    37877- 88110  K
  1991.4283    50215.215     3100     Pt II   104090- 53875  K
  1991.5830    50211.314    12000     Pt I     10116- 60328  N
  1991.8236    50205.249     2500
  1992.1936    50195.924     1300     Pt I     15501- 65697  AN
  1992.1936    50195.924     1300     Pt II    21168- 71364  AK
  1993.52      50162.5         91
  1994.0957    50148.05      2200     Ne II                  C
  1994.46      50138.9        190
  1995.04      50124.3        220     Pt II    23875- 73999  K
  1995.2792    50118.30       240     Ne II                  C
  1995.8991    50102.733    17000     Pt I      6567- 56670  N
  1996.27      50093.4        270     Pt II    58062-108155  K
  1996.80      50080.1         77
  1997.10      50072.6         70
  1997.36      50066.1         42
  1997.8371    50054.131      590     Pt II    32918- 82972  P
  1998.16      50046.0        330
  1998.41      50039.8        140     Pt I     18566- 68606  N
  1998.6681    50033.32       190     Ne II                  C
  1998.86      50028.5        270
  1999.28      50018.0         44
  1999.5947    50010.135      280     Pt I         0- 50010  N
  1999.40      49998.8         76     Ne III                 L
Character descriptor definitions (appear to right of intensity)
Code definitions

Photoelectric spectrum

1984-2000 Å

                      WAVELENGTH (ANGSTROMS) - VACUUM
