Spectrum of Platinum homepage

Lines and intensities in the range 2014-2030 Å.


 WAVELENGTH   WAVENUMBER   INTENSITY    CLASSIFICATION     CODE
 ______________________________________________________________

  2014.9330    49613.421    78000     Pt II    16820- 66434  07
  2015.5192    49598.992     1700     Pt II    43737- 93336  K
  2015.76      49593.1        220
  2016.10      49584.7        300     Pt II    43737- 93322  K
  2016.32      49579.3         41
  2016.6483    49571.226      250     Pt I     13496- 63067  N
  2016.7207    49569.447     3700     Pt I     10116- 59686  N
  2016.9067    49564.877     2500     Pt II    23461- 73026  08
  2017.1136    49559.793      130     Pt II    15791- 65351  05
  2017.68      49545.9        160     Pt II    58491-108037  K
  2018.3288    49529.958     4400     Pt II    24879- 74409  K
  2018.66      49521.8        110
  2019.11      49510.8        230     Pt II    46046- 95557  K
  2019.6648    49497.200      530     Pt II   111162- 61665  K
  2019.8361    49493.004     1400     Pt II   114539- 65046  K
  2020.5434    49475.679    14000     Pt I       823- 50299  N
  2020.68      49472.3        170
  2020.92      49466.5        130
  2021.6302    49449.085      430     Pt I     16983- 66432  N
  2022.9516    49416.791     7800     Pt II   106434- 57018  P
  2023.5420    49402.375     2700     Pt I     15501- 64904  N
  2023.79      49396.3         31
  2024.6363    49375.677     1700     Pt I     10116- 59492  N
  2025.5109    49354.359      250     Pt II    27255- 76610  08
  2025.5585    49353.20       700     Ne II                  C
  2025.6856    49350.104      510
  2025.8727    49345.547     3300     Pt I     10116- 59462  N
  2026.50      49330.3        290     Pt I     10131- 59462  N
  2027.24      49312.3        110     Pt II    41434- 90746  K
  2027.30      49310.8         70
  2027.54      49305.0        220
  2028.3159    49286.116      690     Pt I         0- 49286  D
  2028.5916    49279.420     2100     Pt I       775- 50055  D
Character descriptor definitions (appear to right of intensity)
Code definitions

Photoelectric spectrum

2014-2030 Å

                      WAVELENGTH (ANGSTROMS) - AIR

A PostScript file is available.
